Fast Ethernet fiber optical media converter
Model name: AN-UM100 10/100 BaseT dual fiber fiber optical media converter to 100BaseFX with available distances at 20/40/60/80/100/120 km
10/100Mbps and full/half duplex automatically configure in TP port.
Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX, 100Base-FX Standards
MDI/MDI-X Auto Negotiation
LED Indicators: POWER, FX LINK/ACT, 100, TP LINK/ACT, FDX/COL.
LLR, LFP – Link Loss Return (LLR), Link Failure Pass (LFP) features supported (please mention this when place order or require price, by default this feature is not included)
Optional 19” System Chassis (AN-CH05) holds up to 14 Media Converters
Hot Pluggable & Wall-Mountable
FCC Class A & CE approved
RoHs compliance
- AUTOMATICALLY adapts to 10 Mbit/s, 100 Mbit/s (Fast Ethernet) or 1000 Mbit/s (Gigabit) Speed And Extends Ethernet over Single Mode Single Fiber to up to 20 km (12.42 Miles)
- NO MORE Integration Hassles, simply plug in Ethernet cable to any Ethernet port, whatever speed it is! UPC (Blue) Type Fiber Patch-cords Supported. Only 1 fiber needed - WDM (1310nm/1550nm) wavelengths used
- SUPPORTS Jumbo Frame & LLF feature - for increased end-to-end TCP performance - Configured on demand using Dip-Switches
- PLUG & PLAY - Simply plug in fiber optical port and UTP RJ-45 port, and it will work immediately
- WHAT YOU GET: 1 pair (2 units) media converters and FREE UTP Cat5e Patch Cable (1m - 39in) Comes In The Set With Every Unit! - Colors May Vary Depending on Stock. + Wall Mount Ears comes in set with every unit as well!
