Enterprise Network System Design, consult and Installation
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
10 Port Managed PoE Gigabit Switch
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
LAN Port: 08
SFP Port: 02
Brand: CISCO
Origin: USA
Warranty : 01 Year
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Capacity: 14.88Mbps
Switching capacity: 20Gbps
Packet buffer: 1.5MB
Priority levels: 8 hardware queues
MAC table: 16K addresses
LEDs: System, Link/Act, PoE, Speed
Flash RAM: 256MB
DRAM: 512MB
CPU: 800 MHz ARM
IPv4 routing
Wire-speed routing of IPv4 packets
Up to 128 IP interfaces and 990 static routes
IPv6 routing: Wire-speed routing of IPv6 packets
Layer 3 interface
Link aggregation (LAG)
VLAN interface or loopback interface
Classless Interdomain Routing (CIDR)
Support for classless interdomain routing
RIP v2: Supports routing information protocol version 2 for dynamic routing
Policy-Based Routing (PBR)
Flexible routing control that uses the IPv4 or IPv6 Access Control List to route packets to alternative next hops (ACL)
DHCP server
This switch serves IP addresses for various DHCP pools and scopes and provides support for DHCP options as an IPv4 DHCP server
DHCP relay at layer 3: Transmission of DHCP data between IP domains
User Datagram Protocol (UDP) relay
Relaying broadcast data across layer-3 domains to facilitate application discovery or retransmission of Bootstrap Protocol (BOOTP)/ DHCP packets
Scheduling: Strict priority and Weighted Round-Robin (WRR)
Rate limiting
Ingress policer/ Egress shaping and rate control/ Per VLAN, Per port, and flow based/ 2R3C policing
Congestion avoidance
Global TCP loss synchronization must be reduced and avoided using a TCP congestion avoidance technique
iSCSI traffic optimization: A system for giving iSCSI traffic precedence over other traffic types
Energy detect
When the switch detects a link down, it automatically turns off the power on the RJ-45 port, and when it detects a link up, it resumes active mode without losing any packets
Cable length detection
Signal strength is adjusted according to cable length, and shorter cables use less power
EEE Compliant (802.3az): All copper Gigabit Ethernet ports support IEEE 802.3az
Disable port LEDs: To conserve energy, LEDs can be manually turned off
Time-based port operation: Depending on the user-defined schedule, link up or down (when the port is administratively up)
Time-based PoE: PoE power can be switched on or off according to a user-defined schedule to conserve energy
Jumbo frames: Up to 9K bytes in frame size with a 2K bytes MTU by default
USB slot: The switch's front panel has a USB Type-A slot for simple file and image management
Cabling type: Category 5e or superior Unshielded Twisted Pair (UTP) for 1000BASE-T
Storage temperature is -25° to 70°C
Operating humidity is 10 to 90%, relative, noncondensing
Storage humidity is 10 to 90%, relative, noncondensing
Dimension: 10.56 (W) x 7.28 (D) x 1.73 (H) inch
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Free Service: 1 Year
**** Expert Technical Hand...
**** 24x7 Support Team...
**** Granted After Sales Service...
**** Quality Assured...
**** Service also outside of the city...
**** Home Delivery Facility *****
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Contact us for further info
NET CONNECT
Email: [email protected]
www.netconbd.com
Phone: 01670451543
|
