POWER GUARD PG 650 VA CS UPS (POWER GUARD)
| Main Features: | |
| Automatic voltage ragulation(AVR) Wide Input Voltage Range Option High/Low Voltage Protection Overload/Short Protection Cool start computer even there is no main power Automatic recharge even UPS is off Beeping Alarm LED indicator Frequency Selection Automatically Intelligent Battery Management Compatibility with generators |
|
| Specification: | |
| Brand | POWER GUARD |
| Model | PG 650 VA – C S |
| Power (VA/W) Requirements | 650 VA / 390W |
| Input | |
| Voltage Range | 145-280VAC |
| Frequency | 50/60Hz+/-5% |
| Output | |
| Voltage (Inverter Mode) | 220/230VAC+/-10% |
| Capacity | 390W |
| Frequency (Inverter Mode) | 50/60Hz+/-5% |
| Transfer Time | 2~6ms typical |
| Waveform | Modified-Sinewave |
| Protection | |
| Spike & Surge Suppression | Yes |
| Over/Under Volt. | Switch to Bat. O / P when main over regulation range |
| Over load /short Circuit | Fuse & current linited for both Mains and Battery modes |
| Function | |
| Cool start | Cool start computer even there is no main power |
| Automatic recharge | Automatic recharge even UPS is off |
| INDICATORS | |
| AC Mode | Green lighting |
| Battery Mode | Red lighting |
| Over Load | Yellow lighting |
| Battery | |
| Type | Lead-Acid Miantenance-Free |
| DC Bus | 12V 7.2Ah |
| Number | 1 PCS |
| Recharge time | 6 hours up to 90% capacity |
| Back up time | 05-15 mins (Depending on load) |
| Environmental | |
| Temperature | -5-45 DegreeC |
| Humidity | 20% to 90% |
| Warranty | 01 Year Battery & Service with Spare Parts |
Automatic voltage ragulation(AVR)
Wide Input Voltage Range Option
High/Low Voltage Protection
Overload/Short Protection
Cool start computer even there is no main power
Automatic recharge even UPS is off
Beeping Alarm
LED indicator
Frequency Selection Automatically
Intelligent Battery Management
Compatibility with generators
