ZK-D3180S 18 detection zones interconnected in different areas and simultaneous alarm of multiple zones.

ZK-D3180S

18 Zones

• • 18 detection zones interconnected in different areas and simultaneous alarm of multiple zones.
  • 5.7 "LCD screen.
  • Adjustable sensitivity: Each zone has 256 levels of sensitivity.
  • Remote control.
  • Sound alarm and LEDs to indicate the zone of the detected metal.
  • Automatic counting of people and alarms.
  • Alarm intensity displayed on the panel.
  • Programming password.
  • Designed with high density anti-in fl ammable material.
  • Self-diagnosis function when switched on, without the need for initial or periodic calibration.
  • Easy installation.
  • Modular design for easy maintenance and replacement.
  • Backup battery with duration of 4-8 hours (optional).
  • Harmless to the human body, people with pacemakers, magnetic pendants, prosthetics, pregnant women, etc.

• Technical specifications

  Power supply	AC 85V - 264V
  Operating Temperature	-20 ° C to 50 ° C
  Frequency of Operation	4 KHz - 8 KHz
  External Size	2200mm x 800mm x 580mm
  Internal Arc Size	2010mm x 700mm x 500mm
  Weight	70KG
